Dassault Falcon 2000LX – Blusky

Dassault

Falcon 2000LX

Production Years 2005 - 2013

Aircraft Produced 136

Active Fleet 136

Fleet in Brazil 8

Measurement System:

Aircraft Cabin and Dimensions

Pilots and passengers
Typical Passenger Capacity	10
Maximum Passenger Capacity	12
Single Pilot	No

External dimensions
Length	20.21 m
Height	7.07 m
Wingspan	21.4 m

External dimensions
Length	66.3 ft
Height	23.2 ft
Wingspan	70.2 ft

External dimensions
Length	20.21 m
Height	7.07 m
Wingspan	21.4 m

Cabin dimensions
Length	7.99 m
Height	1.89 m
Width	2.35 m
Flat Floor	Yes

Cabin dimensions
Length	26.2 ft
Height	6.2 ft
Width	7.7 ft
Flat Floor	Yes

Cabin dimensions
Length	7.99 m
Height	1.89 m
Width	2.35 m
Flat Floor	Yes

Luggage capacity
Internal Baggage Volume	3710 L
Internal Baggage Weight	726 kg
External Baggage Volume	-
External Baggage Weight	-

Luggage capacity
Internal Baggage Volume	131 ft³
Internal Baggage Weight	1600 lb
External Baggage Volume	-
External Baggage Weight	-

Luggage capacity
Internal Baggage Volume	3710 L
Internal Baggage Weight	726 kg
External Baggage Volume	-
External Baggage Weight	-

Floor Plan

Cabin cross section

Performance

Engines
Number	2
Manufacturer	Pratt & Whitney
Model	PW308C
Thrust	7000 lb
TBO	7000c
Flat Rating	ISA+15°C

Weights and limits
Maximum Takeoff Weight	19142 kg
Maximum Payload	2461 kg
Maximum Fuel Capacity	7557 kg
Payload with Full Fuel	665 kg
Maximum Operating Speed	0.86 Mach
Cabin Pressure Differential	9.3 psi

Weights and limits
Maximum Takeoff Weight	42200 lb
Maximum Payload	5425 lb
Maximum Fuel Capacity	16660 lb
Payload with Full Fuel	1465 lb
Maximum Operating Speed	0.86 Mach
Cabin Pressure Differential	9.3 psi

Weights and limits
Maximum Takeoff Weight	19142 kg
Maximum Payload	2461 kg
Maximum Fuel Capacity	7557 kg
Payload with Full Fuel	665 kg
Maximum Operating Speed	0.86 Mach
Cabin Pressure Differential	9.3 psi

Speeds
Long-Range Cruise	809 km/h
High-Speed Cruise	893 km/h

Speeds
Long-Range Cruise	437 kt
High-Speed Cruise	482 kt

Speeds
Long-Range Cruise	809 km/h
High-Speed Cruise	893 km/h

Consumption
Long-Range Cruise	678 kg/h
High-Speed Cruise	1043 kg/h

Consumption
Long-Range Cruise	1495 lb/h
High-Speed Cruise	2300 lb/h

Consumption
Long-Range Cruise	678 kg/h
High-Speed Cruise	1043 kg/h

Performance

Range	4105 mn
Takeoff Distance - Sea Level	1702 m
Takeoff Distance - Hot and High	2475 m
Landing Distance	811 m
Maximum Operating Altitude	14326 m

Range	4105 mn
Takeoff Distance - Sea Level	5585 ft
Takeoff Distance - Hot and High	8120 ft
Landing Distance	2660 ft
Maximum Operating Altitude	47000 ft

Range	4105 mn
Takeoff Distance - Sea Level	1702 m
Takeoff Distance - Hot and High	2475 m
Landing Distance	811 m
Maximum Operating Altitude	47000 ft

Photos

Legend and Premises

Range	Passengers: - 4 passengers for aircraft with a range of up to 6,000 nm - 8 passengers for aircraft with a range over 6,000 nm Fuel reserves: NBAA IFR, with an alternate airport at: - 100 nm for FAR Part 23 aircraft - 200 nm for FAR Part 25 aircraft ISA temperature en route.
Interior Cabin Height	Measured at the center of the cabin cross-section.
Passenger Capacity	For single-pilot aircraft, passenger capacity assumes one pilot.
Interior Cabin Length	For jets, measured from the cockpit/cabin partition to the typical location of the lavatory and/or the rearmost passenger seat.
Payload	Passengers + fuel.
Takeoff Distance - Hot and High	At a 5,000 ft elevation airport and a 25°C temperature (ISA +20°C).
Takeoff Distance - Sea Level	At a sea-level airport and a 15°C temperature (ISA).
Legacy 600	Launched in 2003 with a flat floor. In 2008, the aisle between the seats was lowered, increasing the cabin interior height by 5 cm.
TBO (Time Between Overhauls)	Aircraft with two TBO numbers have Williams engines, which have a longer interval when enrolled in the manufacturer’s engine program.
Flat Rating	Maximum temperature at which maximum engine power is maintained without degradation.
