Gulfstream G450 – Blusky

Gulfstream

G450

Production Years 2004 - 2017

Aircraft Produced 351

Active Fleet 351

Fleet in Brazil 4

Measurement System:

Aircraft Cabin and Dimensions

Pilots and passengers
Typical Passenger Capacity	14
Maximum Passenger Capacity	16
Single Pilot	No

External dimensions
Length	27.22 m
Height	7.68 m
Wingspan	23.71 m

External dimensions
Length	89.3 ft
Height	25.2 ft
Wingspan	77.8 ft

External dimensions
Length	27.22 m
Height	7.68 m
Wingspan	23.71 m

Cabin dimensions
Length	11.28 m
Height	1.89 m
Width	2.23 m
Flat Floor	Yes

Cabin dimensions
Length	37 ft
Height	6.2 ft
Width	7.3 ft
Flat Floor	Yes

Cabin dimensions
Length	11.28 m
Height	1.89 m
Width	2.23 m
Flat Floor	Yes

Luggage capacity
Internal Baggage Volume	4786 L
Internal Baggage Weight	907 kg
External Baggage Volume	-
External Baggage Weight	-

Luggage capacity
Internal Baggage Volume	169 ft³
Internal Baggage Weight	2000 lb
External Baggage Volume	-
External Baggage Weight	-

Luggage capacity
Internal Baggage Volume	4786 L
Internal Baggage Weight	907 kg
External Baggage Volume	-
External Baggage Weight	-

Floor Plan

Cabin cross section

Performance

Engines
Number	2
Manufacturer	Rolls-Royce
Model	Tay MK.611-8C
Thrust	13850 lb
TBO	On Condition
Flat Rating	ISA+15°C

Weights and limits
Maximum Takeoff Weight	33838 kg
Maximum Payload	2631 kg
Maximum Fuel Capacity	13282 kg
Payload with Full Fuel	1143 kg
Maximum Operating Speed	Mach 0.88
Cabin Pressure Differential	9.6 psi

Weights and limits
Maximum Takeoff Weight	74600 lb
Maximum Payload	5800 lb
Maximum Fuel Capacity	29281 lb
Payload with Full Fuel	2519 lb
Maximum Operating Speed	Mach 0.88
Cabin Pressure Differential	9.6 psi

Weights and limits
Maximum Takeoff Weight	33838 kg
Maximum Payload	2631 kg
Maximum Fuel Capacity	13282 kg
Payload with Full Fuel	1143 kg
Maximum Operating Speed	Mach 0.88
Cabin Pressure Differential	9.6 psi

Speeds
Long-Range Cruise	850 km/h
High-Speed Cruise	882 km/h

Speeds
Long-Range Cruise	459 kt
High-Speed Cruise	476 kt

Speeds
Long-Range Cruise	850 km/h
High-Speed Cruise	882 km/h

Consumption
Long-Range Cruise	1173 kg/h
High-Speed Cruise	1386 kg/h

Consumption
Long-Range Cruise	2585 lb/h
High-Speed Cruise	3055 lb/h

Consumption
Long-Range Cruise	1173 kg/h
High-Speed Cruise	1386 kg/h

Performance

Range	4328 mn
Takeoff Distance - Sea Level	1707 m
Takeoff Distance - Hot and High	2499 m
Landing Distance	812 m
Maximum Operating Altitude	13716 m

Range	4328 mn
Takeoff Distance - Sea Level	5600 ft
Takeoff Distance - Hot and High	8200 ft
Landing Distance	2663 ft
Maximum Operating Altitude	45000 ft

Range	4328 mn
Takeoff Distance - Sea Level	1707 m
Takeoff Distance - Hot and High	2499 m
Landing Distance	812 m
Maximum Operating Altitude	45000 ft

Photos

Legend and Premises

Range	Passengers: - 4 passengers for aircraft with a range of up to 6.000 nm - 8 passengers for aircraft with a range over 6.000 nm Fuel reserves: NBAA IFR, with an alternate airport at: - 100 nm for FAR Part 23 aircraft - 200 nm for FAR Part 25 aircraft ISA temperature en route.
Interior Cabin Height	Measured at the center of the cabin cross-section.
Passenger Capacity	For single-pilot aircraft, passenger capacity assumes one pilot.
Interior Cabin Length	For jets, measured from the cockpit/cabin partition to the typical location of the lavatory and/or the rearmost passenger seat.
Payload	Passengers + fuel.
Takeoff Distance - Hot and High	At a 5,000 ft elevation airport and a 25°C temperature (ISA +20°C).
Takeoff Distance - Sea Level	At a sea-level airport and a 15°C temperature (ISA).
Legacy 600	Launched in 2003 with a flat floor. In 2008, the aisle between the seats was lowered, increasing the cabin interior height by 5 cm.
TBO (Time Between Overhauls)	Aircraft with two TBO numbers have Williams engines, which have a longer interval when enrolled in the manufacturer’s engine program.
Flat Rating	Maximum temperature at which maximum engine power is maintained without degradation.
